Industrial series stainless steel pneumatic pumps
Stainless steel pneumatic pump, Power Bull series, ratio 4:1, PTFE seals
Flexbimec
Official distributor in Cyprus
Product code: 1079
Stainless steel pneumatic pump, Power Bull series, ratio 4:1, PTFE seals. Flow rate 35 l/min
Heavy duty pneumatic pumps, particularly designed for the supply of fluids under demanding conditions and where a high delivery is required. With cylinder in stainless steel AISI 304 and PTFE gaskets, suitable for the supply of fluids with particular chemical characteristics. It is recommended to check the compatibility of the fluid with the materials of the wetted pump components before use.
Specifications
- PowerCompressed air Min 2 Max 8 bar (30 – 116 psi)
- Compression ratio4:1
- Outlet pressure32 bar (464 psi)
- Flow range35 l/min
- Connection compressed airF 1/2” BSP
- Connection lubricant outletF 3/4” BSP
- Max compressed air consumption280 l/min
- Length suction tube260 mm
- Diameter pneumatic piston80 mm
- GasketsPTFE
- Weight12 kg
